Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
135
Rear trunnion male Mod. L
Material: Aluminium.
DIMENSIONS (mm)
Mod.
Ø
Ø CD
E
EW
L
FL
MR
XD
L-32-20
20
8
34
16
14
20
8
62,5
L-32-25
25
8
38
16
14
20
8
64,5
L-41-32
32
10
45
26
12
22
10
73
L-41-40
40
12
53,5
28
15
25
13
77
L-41-50
50
12
62,5
32
15
27
13
80
L-41-63
63
16
73
40
20
32
17
89
L-41-80
80
16
92
50
24
36
17
99,5
L-41-100
100
20
108,5
60
29
41
21
117,5
Supplied with:
1
x male trunnion
4
x screws
+ = add the stroke
Rear trunnion ball-joint Mod. R
Material: Aluminium.
DIMENSIONS (mm)
Mod.
Ø
ØCD
E
EX
EP
L
FL
MS
XD
Z°
R-41-32
32
10
45
14
10,5
12
22
18
73
4
R-41-40
40
12
53,5
16
12
15
25
18
77
4
R-41-50
50
12
62,5
16
12
15
27
21
80
4
R-41-63
63
16
73
21
15
20
32
23
89
5
R-41-80
80
16
92
21
15
24
36
36
99,5
5
R-41-100
100
20
108,5
25
18
29
41
41
117,5
5
Supplied with:
1
x ball joint
4
x screws
+ = add the stroke
