Accessory combination Mod. I (combination of C + L + S)
Material: Aluminium.
DIMENSIONS (mm)
Mod.
Ø
ØCD
E
L
FL
M
M1
MR
TG
XD
I-41-32
32
10
45
12
22
M6
10
10
32,5
73
I-41-40
40
12
53,5
15
25
M6
10
12
38
77
I-41-50
50
12
62,5
15
27
M8
13
13
46,5
80
I-41-63
63
16
73
20
32
M8
13
17
56,5
89
I-41-80
80
16
92
24
36
M10
16
17
72
99,5
I-41-100
100
20
108,5
29
41
M10
16
21
89
117,5
+ = add the stroke
90
° male trunnion Mod. ZC
Material: Aluminium.
DIMENSIONS (mm)
Mod.
Ø
AH BT
ØCD EA
EW GL
ØHB
L5
MR
RA
UL
UR TE
XD
ZC-32
32
32
8
10
10
26
21
6,6
1,6
10
18
51
31
38
73
ZC-40
40
36
10
12
15
28
24
6,6
1,6
11
22
54
35
41
77
ZC-50
50
45
12
12
16
32
33
9
1,6
13
30
65
45
50
80
ZC-63
63
50
14
16
16
40
37
9
1,6
15
35
67
50
52
89
ZC-80
80
63
14
16
20
50
47
11
2,5
15
40
86
60
66
99,5
ZC-100
100
71
17
20
20
60
55
11
2,5
19
50
96
70
76
117,5
Supplied with:
1
x male support
+ = add the stroke
