Compact and Short-Stroke Cylinders
2
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
COMPACT AND SHORT-STROKE CYLINDERS
133
Foot mount Mod. B
Material: zinc-plated steel.
DIMENSIONS (mm)
Mod.
Ø
ØAB
AH
AO
AU
AT
E
TR
SA
XA
B-32-20
20
6,5
27
9
16
4
35
22
68,8
58,5
B-31-25
25
6,5
29
9
16
4
39
26
70,8
60,5
B-41-32
32
7
32
11
24
4
45
32
92
75
B-41-40
40
10
36
15
28
4
53,5
36
101
80
B-41-50
50
10
45
15
32
4
62,5
45
109
85
B-41-63
63
10
50
15
32
5
73
50
113
89
B-41-80
80
12
63
20
41
6
92
63
136
104,5
B-41-100
100
14,5
71
25
41
6
108,5
71
148,8
117,5
Supplied with:
2
x feet
4
x screws
+ = add the stroke
Rear female trunnion Mod. C and C-H
Material: Aluminium.
DIMENSIONS (mm)
Mod.
Ø
ØCD
E
CB
UB
L
FL
MR
XD
C-41-32
32
10
45
26
45
12
22
10
73
C-41-40
40
12
53,5
28
52
15
25
12
77
C-41-50
50
12
62,5
32
60
15
27
13
80
C-H-41-63
63
16
73
40
70
20
32
17
89
C-H-41-80
80
16
92
50
90
24
36
17
99,5
C-H-41-100
100
20
108,5
60
110
29
41
21
117,5
Supplied with:
1
x female trunnion
4
x screws
+ = add the stroke
