Rod fork end Mod. G
Material: zinc-plated steel ISO 8140.
DIMENSIONS (mm)
Mod.
Ø
ØCK
LE
CM
CL
ER
CE
KK
B
ØB1
G-20
20-25
8
16
8
16
10
32
M8X1,25
22
14
G-25-32
32-40
10
20
10
20
12
40
M10x1,25
26
18
G-40
50-63
12
24
12
24
14
48
M12x1,25
32
20
G-50-63
80-100
16
32
16
32
19
64
M16x1,5
40
26
Piston rod socket joint Mod. GY
Material: zinc-plated steel and Zinc-Aluminum alloy.
DIMENSIONS (mm)
Mod.
Ø
KK
L
CE L2
AX SW SW1
L1
L3
ØT
ØD E ØB ØC Z
GY-20
20-25
M8X1,25
65
32
5
16
14
10
16
12
12,5
13
6
10
20
15
GY-32
32-40
M10X1,25
74
35
6,5
18
17
11
19,5
15
15
19
10
14
28
15
GY-40
50-63
M12X1,25
84
40
6,5
20
19
17
21
17
17,5
22
12
19
32
15
GY-50-63
80-100
M16X1,5
112
50
8
27
22
19
27,5
23
22
27
16
22
40
11
