Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
STAINLESS STELL CYLINDERS
209
Rod fork end Mod. G-90
ISO 8140
Material: stainless steel 303
DIMENSIONS
Mod.
Ø
ØCK
LE
CM
CL
ER
CE
KK
B
ØB1
G-90-25-32
32
10
20
10
20
12
40
M10x1,25
26
18
G-90-40
40
12
24
12
24
14
48
M12x1,25
31
20
G-90-50-63
50-63
16
32
16
32
19
64
M16x1,5
39
26
Swivel ball joint Mod. GA-90
ISO 8139
Material: stainless steel 304
DIMENSIONS
Mod.
Ø
ØCN
U
EN
ER
AX
CE
KK
ØT
Z
SW
GA-90-32
32
10
10,5
14
14
20
43
M10x1,25
15
6,5
17
GA-90-40
40
12
12
16
16
22
50
M12x1,25
17,5
6,5
19
GA-90-50-63
50-63
16
15
21
21
28
64
M16x1,5
22
7,5
22
Piston rod nut Mod. U-90
ISO 4035
Material: stainless steel 304
DIMENSIONS
Mod.
Ø
D
m
SW
U-90-25-32
32
M10x1,25
6
17
U-90-40
40
M12x1,25
7
19
U-90-63
50-63
M16x1,5
8
24
