Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
STAINLESS STELL CYLINDERS
207
Foot mount Mod. B
Material: stainless steel 304
Supplied with:
1
x nut
2
x single feet
DIMENSIONS
Mod.
Ø
A
B
C
D
E
SA+
F
G
ØH
ØM
XD+
B-97-32
32
4
53
35
24
42
142
32
32
30,1
7
142
B-97-40
40
4
63,5
36
28
55
161
36
36
38,1
10
160
B-97-50
50
5
77,5
47
32
65
170
45
45
45,1
10
170
B-97-63
63
5
82,5
45
32
65
185
50
50
45,1
10
190
+ = add the stroke
Trunnion bracket Mod. I
Material: stainless steel 304
Supplied with:
1
x female trunnion
2
x cartridges
DIMENSIONS
Mod.
Ø
C
C1
C2
ØD1
E1
F
G
G1
G2
L1+
SW1
I-97-32
32
40
24
20
7
4
35
38,1
50,1
58,1
27
13
I-97-40
40
50
30
28
9
5
40
46,1
60,1
70,1
33
17
I-97-50
50
54
34
36
9
6
45
57,1
74,1
86,1
40
19
I-97-63
63
65
35
42
9
6
50
70,1
88,1
100,1
45
19
+ = add the stroke
Rear female trunnion bracket Mod. C-H
Material: stainless steel 316
Supplied with:
1
x female trunnion bracket
4
x screws
DIMENSIONS
Mod.
Ø
CB
CD
E
FL
L
MR
UB
XD+
C-H-90-32
32
26
10
45
22
12
10
45
142
C-H-90-40
40
28
12
55
25
15
12
52
160
C-H-90-50
50
32
12
65
27
17
12
60
170
C-H-90-63
63
40
16
75
32
20
16
70
190
+ = add the stroke
