STAINLESS STELL CYLINDERS
Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
206
Cylinders Series 97, Mod. F
With rear female trunnion bracket
DIMENSIONS
Ø ØA AM ØB2 CB CX EE
KK
PL SW1 KW1 SW2 U1 WH L1+ L2+ L3+ L LU XD+ UB
32
12 22 36 14 10
G1/8 M10x1,25 31
17
6
10 23 18 151 133 76 13
9 142 34
40
16 24 45 16 12
G1/4 M12x1,25 38
19
7
13 27 22 170 148 81 16 10 160 40
50
20 32 55 21 16
G1/4 M16x1,5 40,5 24
8
17 33 28,5 182 153,5 82 16,5 12 170 45
63
20 32 68 21 16
G3/8 M16x1,5 48
24
8
17 40 31,5 202 170,5 95 21 12 190 51
+ = add the stroke
Cylinders Series 97, Mod. A
With front end block with pins
DIMENSIONS
Ø ØA AM ØB2 EE
KK
SW SW1 KW1 SW2 U1 WH L1+ L2+ L3+ LU XG TD TL UT
32
12 22
36
G1/8 M10x1,25
8
17
6
10
23
9
120 111
76
9
27 10 7
58
40
16 24
45
G1/4 M12x1,25
8
19
7
13
27 13 135 122
81 12 33 12 9
71
50
20 32
55
G1/4 M16x1,5
8
24
8
17
33 18 143 125
82 12 40 14 9
81
63
20 32
68
G3/8 M16x1,5
12
24
8
17
40 22,5 158 135,5 95 13 45 16 12 104
+ = add the stroke
