Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
STAINLESS STELL CYLINDERS
199
Foot mount Mod. P
Material: stainless steel 304
Supplied with:
1
x nut
2
x single feet
DIMENSIONS (mm)
Mod.
Ø A
AB AO AH C G G1
TR TR1
TR2
TR3
H L1
SA +
XA +
P-92-32
32
24
7
11
32
4
66
53
52
28
32
52
18
46
142
144
P-92-40
40
28
9
15
36
5
80
61
60
30
36
60
21
53
161
163
P-92-50
50
32
9
15
45
6
90
75
70
40
45
70
25
63
170
175
P-92-63
63
32
9
10
50
6
96
85
76
50
50
76
25
63
185
190
+ = add the stroke
Trunnion bracket Mod. I
Material: stainless steel 304
Supplied with:
1
x female trunnion
2
x pins
2
x cartridges
DIMENSIONS (mm)
Mod.
Ø C C1
C3
D1
D2
E1
F
G
G1
G2
L1+
L2
L3+
SW1
I-92-32
32
40
24
20
7
10
4
35
38,1
50,1
58,1
109,5
36,5
105,5
13
I-92-40
40
50
30
28
9
12
5
40
46,1
60,1
70,1
120
45
117
17
I-92-50
50
54
34
36
9
14
6
45
57,1
74,1
86,1
128,5
51,5
124,5
19
I-92-63
63
65
35
42
9
16
6
50
70,1
88,1
100,1
143
52
142
19
+ = add the stroke
Bracket with threaded pins Mod. T
Material: stainless steel 303
Supplied with:
2
x pins
DIMENSIONS (mm)
Mod.
Ø
XV
XV1 +
TD
TM
SW1
T-42-32
32
36,5
109,5
10
51
5
T-42-40
40
45
120
12
62
6
T-42-50
50
51,5
128,5
14
75
6
T-42-63
63
52
143
16
91
8
+ = add the stroke
