STAINLESS STELL CYLINDERS
Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
200
Rod fork end Mod. G-90
Material: stainless steel 303
ISO 8140
DIMENSIONS (mm)
Mod.
Ø CK LE CM CL ER CE
KK
B ØB1
G-90-25-32
32
10 20 10 20 12 40
M10x1,25 26 18
G-90-40
40
12 24 12 24 14 48
M12x1,25 31 20
G-90-50-63
50-63 16 32 16 32 19 64
M16x1,5 39 26
Swivel ball joint Mod. GA-90
Material: stainless steel 304
ISO 8139
DIMENSIONS (mm)
Mod.
Ø CN U EN ER AX CE KK
ØT Z SW
GA-90-32
32 10 10,5 14 14 20 43
M10x1,25 15 6,5 17
GA-90-40
40 12 12 16 16 22 50
M12x1,25 17,5 6,5 19
GA-90-50-63
50-63 16 15 21 21 28 64
M16x1,5 22 7,5 22
Piston rod nut Mod. U-90
Material: stainless steel 304
UNI 5589
DIMENSIONS (mm)
Mod.
Ø
d
m
SW
U-90-25-32
32
M10x1,25
6
17
U-90-40
40
M12x1,25
7
19
U-90-50-63
50-63
M16x1,5
8
24
Nose nut Mod.V-92
Material: stainless steel 304
DIMENSIONS (mm)
Mod.
Ø
D
D1
D2
A
B
C
E
V-92-32
32
M30x1,5
42
36
8
7
37
6,2
V-92-40
40
M38x1,5
50
48
10
9
44
7,2
V-92-50-63
50-63
M45x1,5
60
56
10
9
53
7,2
