STAINLESS STELL CYLINDERS
Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
208
Tight rear female trunnion bracket Mod. CR
Material: stainless steel 316
Supplied with:
1
x female trunnion bracket
4
x screws
DIMENSIONS
Mod.
Ø
B1
B2
E
CN
FL
XD+
CR-90-32
32
14
34
45
10
22
142
CR-90-40
40
16
40
55
12
25
160
CR-90-50
50
21
45
65
16
27
170
CR-90-63
63
21
51
75
16
32
190
+ = add the stroke
Male trunnion bracket with swivel ball joint Mod. R
Material: stainless steel 316
Supplied with:
1
x male trunnion bracket
4
x screws
DIMENSIONS
Mod.
Ø
E
EN
FL
TG1
XD+
R-90-32
32
45
14
22
32,5
142
R-90-40
40
55
16
25
38
160
R-90-50
50
65
21
27
46,5
170
R-90-63
63
75
21
32
56,5
190
+ = add the stroke
90
° male trunnion bracket with swivel ball joint Mod. ZCR
Material: stainless steel 316
Supplied with:
1
x male trunnion bracket
4
x screws
DIMENSIONS
Mod.
Ø
CH
CN
G1
G2
G3
H6
K1
K2
S5
XD+
ZCR-90-32
32
32
10
21
18
31
10
38
51
6,6
142
ZCR-90-40
40
36
12
24
22
35
10
41
54
6,6
160
ZCR-90-50
50
45
16
33
30
45
12
50
65
9
170
ZCR-90-63
63
50
16
37
35
50
12
52
67
14
190
+ = add the stroke
