ROTARY ACTUATORS AND GRIPPERS
259
CODING EXAMPLE
TABLE OF TORQUE FORCE IN Nm (THEORETICAL)
18
-
050
/
090
18
SERIES
050
BORE
032
= 32 mm
040
= 40 mm
050
= 50 mm
063
= 63 mm
080
= 80 mm
100
= 100 mm
125
= 125 mm
090
ROTATIONAL ANGLES
090
= 90°
180
= 180°
Ø
1
bar
2
bar
3
bar
4
bar
5
bar
6
bar
7
bar
8
bar
9
bar
10
bar
32
1,42
2,84
4,26
5,68
7,10
8,50
9,94
11,36
12,77
14,19
40
2,22
4,44
6,65
8,87
11,09
13,31
15,52
17,74
19,96
22,18
50
3,47
6,93
10,40
13,86
17,33
20,79
24,26
27,72
31,19
34,65
63
6,60
13,20
19,81
26,41
33,01
39,61
46,21
52,82
59,42
66,02
80
10,65
21,29
31,94
42,58
53,23
63,87
74,52
85,17
95,81
106,46
100
22,18
44,36
66,54
88,71
110,89
133,07
155,25
177,43
199,61
221,78
125
34,65
69,31
103,96
138,62
173,27
207,92
242,58
277,23
311,90
346,50
