ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
46
ø Rod extension [X]
(
mm)
Holding force
[
static load] (N)
20
+50
300
25
+48
400
32
+40
650
40
+43
1100
50
+57
1600
63
+57
2500
80
+80
4000
100
+80
6300
125
+125
8800
Cylinders Series 62 with rod lock
DIMENSIONS (mm)
Ø ØD ØD1 ØD2 ØD3 A
G H H1
L1 L2 L3 L4 L5 L6
L7
L8 L9+ L10+ M WH Z
32
12 30,5 35 25 32,5
M5 25,5 46,5 58 48 10 8 13 20,5 34
45 94 160
M6 66 M6x20
40
16 35
40 28 38
G1/8 30
53
65 55 10 8 13 22,5 38
50 105 178
M6 73 M6x20
50
20 40
50 35 46,5
G1/8 36
64
82 70 12 15 16 29,5 48
60 106 200
M8 94 M6x20
63
20 45
60 38 56,5
G1/8 40
75
82 70 12 15 16 29,5 49,5 70 121 215
M8 94 M8x30
80
25 45
80 48 72
G1/8 50
95
110 90 20 18 20 35
61
90 128 254
M10 126 M10x35
100
25 55 100 58 89
G1/8 58 110,5 115 100 15 18 20 39
69 105 138 269
M10 131 M10x35
+ = add the stroke
