STAINLESS STELL CYLINDERS
Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG > Release 8.5
196
CODING EXAMPLE
STANDARD STROKES FOR DOUBLE-ACTING CYLINDERS SERIES 92
92 M 2 A 050 A 0200
92 SERIES
M VERSION
M = standard magnetic
2 OPERATION
1 = single-acting (front spring)
2 = double-acting (front and rear cush.)
6 = double-acting (through-rod front and rear cushions)
A MATERIALS
A = stainless steel AISI 316, seals in NBR, (Buna-N)
V = stainless steel AISI 316, all FKM seals, (VITON)
050 BORE (ø):
032 = 32 mm
040 = 40 mm
050 = 50 mm
063 = 63 mm
A TYPE OF DESIGN
A = standard (locking ring for end cap V + lock nut for rod U)
0200 STROKE
(see table)
= standard
V = rod seals in FKM, (VITON)
Ø 25 50 75 80 100 125 150 160 200 250 300 320 400 500
32 ✖■ ✖■ ✖■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
40 ✖■ ✖■ ✖■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
50 ✖■ ✖■ ✖■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
63 ✖■ ✖■ ✖■ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖ ✖
