STAINLESS STELL CYLINDERS
Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
194
Swivel ball joint Mod. GA-90
Material: stainless steel 304
ISO 8139
DIMENSIONS (mm)
Mod.
Ø
CN
U
EN
ER
AX
CE
KK
T
Z
SW
GA-90-32
32
10
10,5
14
14
20
43
M10x1,25
15
6,5
17
GA-90-40
40
12
12
16
16
22
50
M12x1,25
17,5
6,5
19
GA-90-50-63
50-63
16
15
21
21
28
64
M16x1,5
22
7,5
22
GA-90-80-100
80-100
20
18
25
21
33
77
M20x1,5
27,5
7
30
GA-90-125
125
30
25
35
35
51
110
M27x2
40
7,5
41
Piston rod nut Mod. U-90
Material: stainless steel 304
UNI 5589
DIMENSIONS (mm)
Mod.
Ø
D
m
SW
U-90-25-32
32
M10x1,25
6
17
U-90-40
40
M12x1,25
7
19
U-90-50-63
50-63
M16x1,5
8
24
U-90-80-100
80-100
M20x1,5
9
30
U-90-125
125
M27x2
12
41
