Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
STAINLESS STELL CYLINDERS
193
Rod fork end Mod. G-90
Material: stainless steel 303
ISO 8140
DIMENSIONS (mm)
Mod.
Ø
CK
LE
CM
CL
ER
CE
KK
B
B1
G-90-25-32
32
10
20
10
20
12
40
M10x1,25
26
18
G-90-40
40
12
24
12
24
14
48
M12x1,25
31
20
G-90-50-63
50-63
16
32
16
32
19
64
M16x1,5
39
26
G-90-80-100
80-100
20
40
20
40
25
80
M20x1,5
50
34
G-90-125
125
30
54
30
55
38
110
M27x2
67
48
Clevis pin Mod. S-90
Material: stainless steel 303
DIMENSIONS (mm)
Mod.
Ø
d
L
L1
L2
L3
S-90-32
32
10
53
46
1,1
3
S-90-40
40
12
60
53
1,1
3
S-90-50
50
12
68
61
1,1
3
S-90-63
63
16
78
71
1,1
3
S-90-80
80
16
98
91
1,1
3
S-90-100
100
20
118
111
1,3
5
S-90-125
125
25
139
132
1,3
4,2
