The company reserves the right to vary models and dimensions without notice.
These products are designed for industrial applications and are not suitable for sale to the general public.
STAINLESS STELL CYLINDERS
Stainless Steel Cylinders
3
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
198
Cylinders Series 92
DIMENSIONS (mm)
Ø A
KK
B
B2
C
D2
F
SW1
SW2
AM WH L1+ L2+ L3
L4
L7
32
12
M10x1,25
M30x1,5
35
G1\8
M8x1
10.5
10
17
22
26
120
94
48
18
14
40
16
M12x1,25
M38x1,5
44
G1\4
M10x1
15
13
19
24
30
135
105
54
22
16
50
20
M16x1,5
M45x1,5
54
G1\4
M12x1.5
14.5
17
24
32
37
145
106
69
25
18
63
20
M16x1,5
M45x1,5
67
G3\8
M14x1.5
15
17
24
32
37
158
121
69
25
18
+ = add the stroke
Cylinders Series 92 - through-rod
DIMENSIONS (mm)
Ø A AM
B
F
C
KK
SW1
SW2
WH L++ L1+ L2+ L3
L4
B2
D2
32
12
22
M30x1,5
10,5
G1\8
M10x1,25
10
17
26
190
120
94
48
18
35
M8x1
40
16
24
M38x1,5
15
G1\4
M12x1,25
13
19
30
213
135
105
54
22
44
M10x1
50
20
32
M45x1,5
14,5
G1\4
M16x1,5
17
24
37
244
143
106
69
25
54
M12x1,5
63
20
32
M45x1,5
15
G3\8
M16x1,5
17
24
37
259
158
121
69
25
67
M14x1,5
+ = add the stroke
++ = add the stroke 2 times
