Max. axial load F with F1 = 0
M = Center of Gravity of the applied theorical load.
Max. radial load F1 with F = 0
Ø
32
40
50
63
80
100
125
Force F
100
N
100
N
120
N
120
N
200
N
250
N
300
N
AXIAL LOAD
RADIAL LOAD
