ROTARY ACTUATORS AND GRIPPERS
Rotary Actuators and Grippers
5
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
268
Rotary cylinders Series 30
DIMENSIONS (mm)
Mod.
A
B
C
D E F
h7
G H L
M N
O
P
Q R S T
30-50-090
48
62
162
36
2.5
15
25
5
5
25
G1/8
23
M8 x 1.25
46
98
8
8
30-63-090
60
76
186
41
2.5
17
30
6
5
30
G1/8
24
M10 x 1.5
57
117
8
12
30-80-090
72
92
195
50
3
20
35
6
5
35
G1/4
23,5
M12 x 1.75
70
142
9
13
30-100-090
85
112
247
60
4
25
40
8
5
40
G3/8
26
M12 x 1.75
85
172
9
14
30-50-180
48
62
199
36
2.5
15
25
5
5
25
G1/8
26
M8 x 1.25
46
98
8
8
30-63-180
60
76
237
41
2.5
17
30
6
5
30
G1/8
24
M10 x 1.5
57
117
8
12
30-80-180
72
92
245
50
3
20
35
6
5
35
G1/4
23,5
M12 x 1.75
70
142
9
13
30-100-180
85
112
313
60
4
25
40
8
5
40
G3/8
26
M12 x 1.75
85
172
9
14
XX = Screw for stroke
regulation
Rotary cylinders Series 30
DIMENSIONS (mm)
Mod
A
B
C
D E F
h7
G H L
M N
O
P
Q R S T
30-050/090-3
48
62
150
36
2.5
15
25
5
5
25
G1\8
17
M8 x 1.25
46
98
8
8
30-063/090-3
60
76
172
41
2.5
17
30
6
5
30
G1\8
17
M10 x 1.5
57
117
8
12
30-080/090-3
72
92
191
50
3
20
35
6
5
35
G1\4
21,5
M12 x 1.75
70
142
9
13
30-100/090-3
85
112
245
60
4
25
40
8
5
40
G3\8
25
M12 x 1.75
85
172
9
14
30-050/180-3
48
62
187
36
2.5
15
25
5
5
25
G1\8
17
M8 x 1.25
46
98
8
8
30-063/180-3
60
76
233
41
2.5
17
30
6
5
30
G1\8
17
M10 x 1.5
57
117
8
12
30-080/180-3
72
92
241
50
3
20
35
6
5
35
G1\4
21,5
M12 x 1.75
70
142
9
13
30-100/180-3
85
112
311
60
4
25
40
8
5
40
G3\8
25
M12 x 1.75
85
172
9
14
XX = Screw for stroke
regulation
