ROTARY ACTUATORS AND GRIPPERS
Rotary Actuators and Grippers
5
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
280
DIMENSIONS (mm)
Mod.
W thread
W depth
Z thread
Z depth
AA thread
AA depth
CGA-10
M3
7
M3
-
M3
-
M3
-
M3
5
CGA-16
M4
11
M5
-
M4
-
M3
-
M4
7
CGA-20
M5
13
M5
-
M5
-
M4
-
M5
8
CGA-25
M6
15
M5
-
M6
-
M5
-
M6
10
CGA-32
M6
20
M5
-
M6
-
M6
-
M6
10
Y = port connection
Z = claw mounting-hole
X.W.AA = Mounting hole
DIMENSIONS
Mod.
A B C D E F
G H I
J
K L M N O P Q R S T U V
CGA-10 10 30,5 15,5 15,7 18 20 30,5 36,5 14 2,5 1,5 0°
10 7,5 19 6 3 7 16 10 23 17
CGA-16 14 38
21 17,5 24 25,5 38 45,5 24 3
3 0
°
12 7,5 25,5 8 3 9 22 14 34 26
CGA-20 16 42,5 22
22 30 28 42,5 53 30 3,5 3,5 0
°
13 8
28 10 4 12 26 16 45 35
CGA-25 20 48,5 24,5 26 36 31,5 48,5 61 36 4,5 4,5 0°
18 9
31 12 5 14 32 20 52 40
CGA-32 26 54
30
30 44 37,5 45
68 42 5
5 0
°
24 10 33,5 14 6 18 40 26 60 46
