ROTARY ACTUATORS AND GRIPPERS
Rotary Actuators and Grippers
5
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
270
ARP
SERIES
001
SIZE:
001
= torque force 9 Nm
003
= torque force 24 Nm
005
= torque force 50 Nm
010
= torque force 100 Nm
012
= torque force 120 Nm
020
= torque force 200 Nm
035
= torque force 370 Nm
055
= torque force 597 Nm
070
= torque force 825 Nm
100
= torque force 1122 Nm
150
= torque force 1655 Nm
250
= torque force 2648 Nm
400
= torque force 4800 Nm
1
A
OPERATION:
1
A = single-acting, minimum pressure of 4 bar
1
B = single-acting, minimum pressure of 5 bar
1
C = single-acting, minimum pressure of 5,5 bar
1
D = single-acting, minimum pressure of 6 bar
2
A = double-acting
A
ROTATION ANGLE:
A = 90°
F0300
INTERFACE FOR FLANGE (ISO 5211):
F0300 = flange holes F03
F0305 = flange holes F03 + flange holes F05
F0400 = flange holes F04
F0507= flange holes F05 + flange holes F07
F0700 = flange holes F07
F0710 = flange holes F07 + flange holes F10
F1200 = flange holes F12
F1400 = flange holes F14
F1600 = flange holes F16
F1625 = flange holes F16 + flange holes F25
A
MATERIALS:
A = standard anodized
E = epoxy (epoxy coating and stainless steel shaft)
C = CNI Kanigen type nickel-plating
W = high temperatures (200°C)
HW = very high temperatures (250°C)
EX
ATEX certified product
CODING EXAMPLE
ARP -
001 -
1
A A -
F0300 -
A EX
