ROTARY ACTUATORS AND GRIPPERS
Rotary Actuators and Grippers
5
NORTH AMERICAN CYLINDER & ACTUATOR CATALOG
>
Release 8.5
272
DOUBLE-ACTING
models
3
bar
4
bar
5
bar
5,5
bar
6
bar
7
bar
ARP-001-2A
4,4
5,8
7,33
8,0
8,8
10,2
ARP-003-2A
11,8
15,8
19,7
21,7
23,7
27,6
ARP-005-2A
25,3
33,8
42,2
46,4
50,7
59,1
ARP-010-2A
50,7
67,6
84,5
92,9
101,4
118,3
ARP-012-2A
61,2
81,6
102,1
112,2
122,5
142,9
ARP-020-2A
100,9
134,6
168,2
185,08
201,9
235,5
ARP-035-2A
187,0
249,3
311,6
342,8
374,0
436,3
ARP-055-2A
298,5
398,0
497,5
547,2
597,0
696,5
ARP-070-2A
412,5
550,0
687,5
756,2
825,0
962,5
ARP-100-2A
561,0
748,0
935,0
1028,5
1122,0
1309,0
ARP-150-2A
827,5
1103,3
1379,1
1517,0
1655,0
1930,8
ARP-250-2A
1324,0
1765,3
2206,6
2427,3
2648,0
3089,3
ARP-400-2A
2401,5
3202,0
4002,5
4402,7
4803,0
5603,5
SINGLE-ACTING
models
(
for rotation angles of 90°)
Quantity of springs
External - Internal
Spring torque (Nm)
0
° - 90°
Supply pressure of 4 bar
0
° - 90°
Supply pressure of 5 bar
0
° - 90°
Supply pressure of 5,5 bar
0
° - 90°
Supply pressure of 6 bar
0
° - 90°
ARP-003-1AA
8 - /
5,36 - 10,48
10,40 - 5,30
11,80 - 7,90
16,40 - 11,20
18,30 - 13,20
ARP-003-1BA
10 - /
6,70 - 13,10
13,10 - 6,70
15,00 - 8,60
17,00 - 10,60
ARP-003-1CA
11 - /
7,37 - 14,41
14,40 - 7,30
16,30 - 9,30
ARP-003-1DA
12 - /
8,04 - 15,72
13,70 - 6,00
15,70 - 8,00
ARP-005-1AA
8 - /
12,00 - 21,76
21,80 - 12,00
30,30 - 20,50
34,50 - 34,70
38,70 - 28,90
ARP-005-1BA
10 - /
15,00 - 27,20
27,30 - 15,10
31,50 - 19,30
35,70 - 23,50
ARP-005-1CA
11 - /
16,50 - 29,92
30,00 - 16,60
34,20 - 20,80
ARP-005-1DA
12 - /
18,00 - 32,64
28,50 - 13,80
32,70 - 18,10
ARP-010-1AA
8 - /
26,72 - 40,96
40,90 - 26,60
57,80 - 43,50
66,20 - 52,00
74,70 - 60,40
ARP-010-1BA
10 - /
33,40 - 51,20
51,10 - 33,30
59,60 - 41,80
68,00 - 50,20
ARP-010-1CA
11 - /
36,74 - 56,32
56,20 - 36,60
64,70 - 45,10
ARP-010-1DA
12 - /
40,08 - 61,44
52,90 - 31,50
61,30 - 40,00
ARP-012-1AA
4 - 0
28,80 - 52,40
52,90 - 29,30
73,30 - 49,70
83,50 - 59,90
93,70 - 70,10
ARP-012-1BA
4 - 2
36,00 - 65,50
54,70 - 16,20
66,10 - 36,60
76,30 - 46,80
86,50 - 57,00
ARP-012-1CA
4 - 3
39,60 - 72,10
62,50 - 30,00
72,70 - 40,30
82,90 - 50,50
ARP-012-1DA
4 - 4
43,20 - 78,60
58,90 - 23,50
69,10 - 33,70
79,30 - 43,90
ARP-020-1AA
4 - 0
47,70 - 86,80
86,90 - 47,80
120,60 - 81,50
137,40 - 98,30
154,20 - 115,10
ARP-020-1BA
4 - 2
53,70 - 108,50
75,00 - 26,10
108,60 - 59,80
125,40 - 76,60
142,30 - 93,40
ARP-020-1CA
4 - 3
65,50 - 119,40
102,60 - 48,90
119,50 - 65,80
136,30 - 82,60
ARP-020-1DA
4 - 4
71,60 - 130,20
96,70 - 38,10
113,50 - 54,90
130,30 - 71,70
ARP-035-1AA
4 - 0
88,40 - 160,80
161,00 - 88,70
223,40 - 151,00
254,60 - 182,20
285,70 - 213,40
ARP-035-1BA
4 - 2
110,50 - 201,00
138,90 - 48,50
201,30 - 110,80
232,50 - 142,00
263,60 - 173,20
ARP-035-1CA
4 - 3
121,60 - 221,10
190,20 - 90,70
221,40 - 121,90
252,60 - 153,10
ARP-035-1DA
4 - 4
132,60 - 241,20
179,20 - 70,60
210,40 - 101,80
241,50 - 133,00
ARP-055-1AA
4 - 0
141,00 - 256,40 256,80 - 141,40
356,30 - 240,90
406,00 - 290,60
455,70 - 340,30
ARP-055-1BA
4 - 2
176,30 - 320,50
221,60 - 77,30
321,00 - 176,80
370,70 - 226,50
420,50 - 279,20
ARP-055-1CA
4 - 3
193,90 - 352,60
303,40 - 144,70
353,10 - 194,50
402,80 - 244,20
ARP-055-1DA
4 - 4
211,50 - 384,60
285,80 - 112,70
335,50 - 162,40
385,20 - 212,10
ARP-070-1AA
4 - 0
195,0 - 354,0
355,0 - 196,0
493,0 - 333,0
561,0 - 402,0
630,0 - 471,0
ARP-070-1BA
4 - 2
243,0 - 443,0
306,0 - 107,0
444,0 - 245,0
513,0 - 314,0
581,0 - 382,0
ARP-070-1CA
4 - 3
268,0 - 487,0
420,0 - 201,0
488,0 - 269,0
557,0 - 338,0
ARP-070-1DA
4 - 4
292,0 - 531,0
395,0 - 156,0
464,0 - 225,0
533,0 - 294,0
ARP-100-1AA
4 - 0
265,0 - 482,0
483,0 - 266,0
670,0 - 453,0
764,0 - 547,0
857,0 - 640,0
ARP-100-1BA
4 - 2
331,0 - 603,0
417,0 - 146,0
604,0 - 333,0
697,0 - 426,0
791,0 - 520,0
ARP-100-1CA
4 - 3
365,0 - 663,0
571,0 - 272,0
664,0 - 366,0
758,0 - 459,0
ARP-100-1DA
4 - 4
398,0 - 723,0
538,0 - 212,0
631,0 - 306,0
725,0 - 399,0
ARP-150-1AA
4 - 0
391,0 - 711,0
712,0 - 392,0
988,0 - 668,0
1126,0 - 806,0
1264,0 - 944,0
ARP-150-1BA
4 - 2
489,0 - 889,0
615,0 - 215,0
890,0 - 491,0
1028,0 - 629,0
1166,0 - 766,0
ARP-150-1CA
4 - 3
538,0 - 977,0
842,0 - 402,0
979,0 - 540,0
1117,0 - 678,0
ARP-150-1DA
4 - 4
586,0 - 1066,0
793,0 - 313,0
931,0
v451,0
1069,0 - 589,0
ARP-250-1AA
6 - /
606,0 - 936,0
1159,0 - 829,0
1600,0 - 1270,0
1821,0 - 1491,0
2042,0 - 1712,0
ARP-250-1BA
8 - /
808,0 - 1248,0
957,0 - 517,0
1398,0 - 958,0
1619,0 - 1179,0
1840,0 - 1400,0
ARP-250-1CA
9 - /
909,0 - 1404,0
1297,0 - 802,0
1518,0 - 1023,0
1739,0 - 1244,0
ARP-250-1DA
10 - /
1010,0 - 1560,0
1196,0 - 646,0
1417,0 - 867,0
1638,0 - 1088,0
ARP-400-1AA
10 - /
1180,0 - 1820,0 2022,0 - 1382,0
2823,0 - 2183,0
3223,0 - 2583,0
3623,0 - 2983,0
ARP-400-1BA
12 - /
1416,0 - 2184,0 1786,0 - 1018,0
2587,0 - 1819,0
2987,0 - 2219,0
3387,0 - 2619,0
ARP-400-1CA
15 - /
1770,0 - 2730,0
2233,0 - 1273,0
2633,0 - 1673,0
3033,0 - 2073,0
ARP-400-1DA
16 - /
1888,0 - 2912,0
2515,0 - 1491,0
2915,0 - 1891,0
TORQUE FORCE TABLE (Nm)
