ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
48
Rear female trunnion Mod. C and C-H
Material: Aluminium
Mod.
Ø
CD
L
FL
XD+
MR
E
CB
UB
torque force
C-41-32
32
10
12
22
142
10
45
26
45
6
Nm
C-41-40
40
12
15
25
160
13
52
28
52
6
Nm
C-41-50
50
12
15
27
170
13
63
32
60
13
Nm
C-H-41-63
63
16
20
32
190
15
73
40
70
13
Nm
C-H-41-80
80
16
24
36
210
15
95
50
90
19
Nm
C-H-41-100
100
20
29
41
230
18
115
60
110
26
Nm
Supplied with:
1
x female trunnion
4
x screws
+ = add the stroke
Front female trunnion Mod. H and C-H
Material: Aluminium
Mod.
Ø
CB
UB
E
XD
FL
L
CD
MR
H-41-32
32
26
45
45
120
22
12
10
10
H-41-40
40
28
52
52
135
25
15
12
13
H-41-50
50
32
60
63
143
27
15
12
13
H-60-63
63
40
70
73
158
32
20
16
15
C-H-41-80
80
50
90
95
174
36
24
16
15
C-H-41-100
100
60
110
115
189
41
29
20
18
Supplied with:
1
x female trunnion
4
x screws
+ = add the stroke
