ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
47
Foot mount Mod. B
Material: zinc-plated steel
Mod.
Ø
AT
SA+
XA+
TR
E
AB
AH
AO
AU
B-41-32
32
4
142
144
32
45
7
32
11
24
B-41-40
40
4
161
163
36
53,5
10
36
15
28
B-41-50
50
4
170
175
45
62,5
10
45
15
32
B-41-63
63
5
185
190
50
73
10
50
15
32
B-41-80
80
6
210
216
63
92
12
63
20
41
B-41-100
100
6
220
230
75
108,5
14,5
71
25
41
Supplied with:
2
x feet
4
x screws
+ = add the stroke
Front and rear flange Mod. D-E
Material: aluminium
Mod.
Ø
W
MF
ZB+
TF
R
UF
E
FB
ZF+
torque force
D-E-41-32
32
16
10
120
64
32
86
45
7
130
6
Nm
D-E-41-40
40
20
10
135
72
36
88
52
9
145
6
Nm
D-E-41-50
50
25
12
143
90
45
110
63
9
155
13
Nm
D-E-41-63
63
25
12
158
100
50
116
73
9
170
13
Nm
D-E-41-80
80
30
16
174
126
63
148
95
12
190
19
Nm
D-E-41-100
100
35
16
189
150
75
176
115
14
205
22
Nm
Supplied with:
1
x flange
4
x screws
+ = add the stroke
