ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
69
Foot mount Mod. B
Material: black-painted steel
(
cataphoresis)
Supplied with:
2
x feet
4
x screws
DIMENSIONS (mm)
Mod.
Ø
AT
SA +
XA+
TR
E
ØAB
AH
AO
AU
B-41-160
160
10
300
320
115
175
18
115
20
60
B-41-200
200
11
320
345
135
215
22
135
30
70
B-41-250
250
20
350
380
165
270
28
165
35
75
B-41-320
320
20
390
425
200
353
35
200
45
85
+ = add the stroke
Front and rear flange Mod. D-E
Material: Aluminium.
Supplied with:
1
x flange
4
x screws
DIMENSIONS (mm)
Mod.
Ø
W
MF
ZB+
TF
R
UF
G1
ØFB
ZF +
D-E-41-160
160
60
20
260
230
115
276
175
18
280
D-E-41-200
200
70
25
275
270
135
312
215
22
300
D-E-41-250
250
80
25
305
330
165
390
240
26
330
D-E-41-320
320
90
30
340
400
200
470
334
33
370
+ = add the stroke
Front and rear female trunnion Mod. C-H
Material: Aluminium.
Supplied with:
1
x female trunnion
4
x screws
DIMENSIONS (mm)
Mod.
Ø
ØCD
L
FL
D+
XD+
MR
E
CB
UB
C-H-41-160
160
30
35
55
180
315
30
175
90
170
C-H-41-200
200
30
35
60
180
335
30
215
90
170
C-H-41-250
250
40
45
70
-
375
40
270
110
200
C-H-41-320
320
45
50
80
220
420
45
350
120
220
+ = add the stroke
