Cylinders Series 40 with centre trunnion Mod. F
DIMENSIONS (mm)
Ø
XV1
XV2+ 1/2
XV3+
TM
TK
TD
TL
UW
R
160
145
170
195
200
40
32
32
200
0,2
200
160
185
210
250
40
32
32
250
0,2
250
185
205
225
320
50
40
40
300
-
320
210,5
230
249,5
400
70
50
50
400
-
+ = add the stroke
