ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
65
CODING EXAMPLE
STANDARD STROKES FOR DOUBLE-ACTING CYLINDERS SERIES 40
40
M 2
L
160
A
0200
40
SERIES
M
VERSION:
M = standard, magnetic
2
OPERATION:
2
= double-acting (front and rear cushions)
3
= double-acting (no cushion)
4
= double-acting (rear cushions)
5
= double-acting (front cushion)
6
= double-acting (through-rod with front and rear cushions)
L
MATERIALS:
L = see the general data on page 1/1.10.01
T = stainless steel AISI 420B tie-rods - stainless steel AISI 303 tie-rod nuts
C = rolled stainless steel AISI 303 piston rod, stainless steel AISI 304 piston rod nut
U = rolled stainless steel AISI 303 piston rod, stainless steel AISI 304 piston-rod nut,
stainless steel AISI 420B tie-rods, stainless steel AISI 303 tie-rod nuts
W = rolled stainless steel AISI 304 piston rod, stainless steel AISI 304 piston-rod nut,
stainless steel AISI 420B tie-rods, stainless steel AISI 303 tie-rod nuts
Note: rod of cylinders with bore of 250 mm = C40 chrome plated steel.
160
BORE:
160
= 160 mm
200
= 200 mm
250
= 250 mm
320
= 320 mm
A
TYPE OF BRACKET:
A = standard
F = cylinder with centre trunnion
0200
STROKE
see table
= standard
V = FKM rod seals
W = all FKM seals, up to 140°C
C = PU coated cylinder. Colour: Grey *
( _ _ _ )
= extended piston rod _ _ _ mm
Notes: the C version is available on request. For further details, contact our technical dept.
The W and C versions are available for diameters 160 and 200 only.
The V version is available for diameters 160, 200 and 250 only.
■ = Double-acting cylinders
Ø 25
50
75
80
100
125
150
160
200
250
300
320
400
500
160
■
■
■
■
■
■
■
■
200
■
■
■
■
250
■
■
■
■
320
■
■
■
■
MAXIMUM STROKE LENGTHS (mm)
Series (and Ø)
Min-Max Stroke (Produced in USA)
Min-Max Stroke (Produced in Italy)
40, 41 (
Ø 160-320)
10-1500
mm
10-2500
mm
