ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
49
Rear trunnion, male Mod. L
Material: aluminium
Mod.
Ø
CD
L
FL
XD+
MR
E
EW
torque force
L-41-32
32
10
12
22
142
9
45
26
6
Nm
L-41-40
40
12
15
25
160
13
52
28
6
Nm
L-41-50
50
12
15
27
170
13
63
32
13
Nm
L-41-63
63
16
20
32
190
15
73
40
13
Nm
L-41-80
80
16
24
36
210
15
95
50
19
Nm
L-41-100
100
20
29
41
230
18
115
60
22
Nm
Supplied with:
1
x male trunnion
4
x screws
+ = add the stroke
Trunnion ball-joint Mod. R*
Material: Aluminium
*
not according to standard
Mod.
Ø
CX
L
DL
XN+
MS
E
EX
EP
Z
Torque force
R-41-32
32
10
12
22
142
16
45
14
10,5
4
6
Nm
R-41-40
40
12
15
25
160
20
52
16
12
4
6
Nm
R-41-50
50
12
15
27
170
20
63
16
12
4
13
Nm
R-41-63
63
16
20
32
190
24
73
21
15
4
13
Nm
R-41-80
80
16
24
36
210
24
95
21
15
4
19
Nm
R-41-100
100
20
29
41
230
30
115
25
18
4
22
Nm
Supplied with:
1
x trunnion ball-joint
4
x screws
