ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
53
Self aligning rod Mod. GK
Material: zinc-plated steel
Mod.
Ø
KK
L
L1
L3
L4 ØA ØD H I
SW SW1
SW2
B1
AX Z E
GK-25-32
25-32
M10x1,25
71,5
35
20
7,5
14
22
32
30
19
12
17
5
22
4
2
GK-40
40
M12x1,25
75,5
35
24
7,5
14
22
32
30
19
12
19
6
22
4
2
GK-50-63
50-63
M16x1,5
104
53
32
10
22
32
45
41
27
20
24
8
30
3
2
GK-80-100
80-100
M20x1,5
119
53
40
10
22
32
45
41
27
20
30
10
37
3
2
Coupling piece Mod. GKF
Material: zinc-plated steel
Mod.
Ø
KK
A
B
R TF
L
L1
I
Ø D Ø D1
Ø D2
SW E
GKF-25-32
32
M10x1,25
37
60
23
36
22,5
15
6,8
18
11
6,6
15
2
GKF-40
40
M12x1,25
56
60
38
42
22,5
15
9
20
15
9
15
2,5
GKF-50-63
50-63
M16x1,5
80
80
58
58
26,5
15
10,5
25
18
11
22
2,5
GKF-80-100
80-100
M20x1,5
90
90
65
65
32,5
20
13
30,5
20
14
27
2,5
