ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
57
Rod Lock Series RL
ø 20 - 25.
DIMENSIONS (mm)
Mod.
Ø
D
A
D1
H
L
L1
L2
L3
L4
L5
L6
RLC-24-20
20
8
20
38
21
40
58
35
23
12
24
40
RLC-24-25
25
10
20
38
21
40
58
35
23
12
24
40
Rod Lock Series RL
ø 32 - 125.
DIMENSIONS (mm)
Mod.
Ø D D1 D2 D3
G L1 L2 L3 L4 L5 L6
L7
L8
A M H H1
Z
RLC-41-32
32 12 30,5 35 25
M5
58 48 10 8 13 20,5 34
45 32,5
M6 25,5 46,5 M6X20
RLC-41-40
40 16 35
40 28
G1/8 65 55 10 8 13 22,5 38
50
38
M6
30
53
M6X20
RLC-41-50
50 20 40
50 35
G1/8 82 70 12 15 16 29,5 48
60 46,5
M8
36
64
M8X30
RLC-41-63
63 20 45
60 38
G1/8 82 70 12 15 16 29,5 49,5 70 56,5 M8
40
75
M8X30
RLC-41-80
80 25 45
80 48
G1/8 110 90 20 18 20 35
61
90
72
M10 50
95
M10X35
RLC-41-100
100 25 55 100 58
G1/8 115 100 15 18 20 39
69 105 89
M10 58 110,5 M10X35
RLC-41-125
125 32 60 130 65
G1/8 167 122 45 22 30 51 86,5 140 110 M12 80
150
M12X40
