ISO / VDMA CYLINDERS
ISO / VDMA Cylinders
1
60
B = centre of gravity for applied load
L = load
X = fixed projection + stroke
fixed projection = distance to the centre of gravity
Guide “HB” with linear ball bearing (45NHB)
B = centre of gravity for applied load
L = load
X = fixed projection + stroke
fixed projection = distance to the centre of gravity
Guide “HT” bushing support (45NHT)
APPLICABLE LOADS DEPENDING ON PROJECTION - GRAPH 2
APPLICABLE LOADS DEPENDING ON PROJECTION - GRAPH 3
